Chlodnica
Frostbite : FB230
Nr artykułu: FRBFB230
* 100 Percent TIG Welded Seams * Aircraft Quality Aluminum Core/Fittings/Tanks * Billet Aluminum Filler Neck And OEM Brass Petcock * More Cooling Fins Per Inch For More Efficient Cooling * Custom Frostbite High Performance 16 lb. Radiator Cap * Polished Top And Tanks For Custom Show Appearance * Applications Supporting Up To 1000+ Horsepower
Aluminum Radiator; 4-Row; 1 1/2 in. Inlet; 1 3/4 in. Outlet; 23 3/4 x 25 1/8 in. Overall; Bracket Mount;
- Cooling Row Diameter: 0.6875 in.
- Core Dimension: 17.125 in. x 21.500 in.
- Core Thickness: 2.760 in.
- Flow Style: Down Flow
- Hose Location Inlet: Center
- Hose Location Outlet: Passenger
- Inlet Diameter: 1.500 in.
- Item Height: 23.750 in.
- Material: Aluminum
- Mount Type: Bracket Mount
- Mounting: Bracket Mount
- Outlet Diameter: 1.750 in.
- Overall Dimension: 23.750 in. x 25.125 in.
- Overall Length: 25.125 in.
- Radiator Core Row Quantity: 4
- Transcooler Provision: 0.500 in. -20 Straight Thread G 0.250 in.
